£388.63 £466.36 inc VAT
In stock and ready for dispatch
Anti-Static Flexible Ducting 200mm Diameter 10 Meter Length 350 AS BLACK (MD) (350-0200-3030)
• Diameter: 200mm
• Length: 10 Meter
• Working Temperature: -40°C to 90°C, short time to 125°C
• Medium-heavy Duty
• Wall Thickness: 0,7 mm approx
Applications:
• flexible hose/ducting for abrasive powder, bulk material, granulate and for gases
• air supply: UV dryer, IR dryer
• extraction unit, dedusting system, filter system, oil mist extraction
• explosion hazard area
• textile industry, fiber extraction: spinning machine, knitting machine, weaving loom machine
• clean room ventilation, semiconductor production machine
• heating hose: exterior hose as protection hose
• surface preparation: shot blasting/ sand blasting recovery e.g. at blasting chamber, ship yard, stripping machine, flooring preparation machine, grinding machine
Properties:
• medium-heavy duty
• highly abrasion resistant
• good resistance to oil, gasoline and chemicals
• very good low temperature flexibility
• permanently antistatic wall: according to ISO 8031 electrical and surface resistance <10⁹ Ω (according to TRGS 727 <2,5*10⁸ Ω*m and NFPA 652 10⁸-10⁹ Ω)
• in accordance with ATEX 2014/34/EU (1999/92/EC) and German TRGS 727: pneumatic transport of flammable dusts and bulk materials (Zone 20, 21, 22 inside), aspiration of combustible dusts (Zone 22 inside),
• in accordance with ATEX 2014/34/EU (1999/92/EC) and German TRGS 727: for conveying for flammable liquids (inside zone 0, 1, 2), for conveying for non-flammable liquids, for use in zone 1 and 2 (gases), for use in zone 0 (gases)
• according to DIN 26057 Type 2
• conforms to RoHS guideline
• REACH according to --> Technology / Technical Information / REACH
Design:
• AIRDUC® profile hose
• 1. spring steel wire firmly embedded in wall
• 2. wall: permanently antistatic premium ester-polyurethane (Pre-PUR®)
• 3. wall thickness 0,7 mm approx.
Please call if you require any assistance or help choosing the correct products. Our aim is to ensure that your purchase goes smoothly and is delivered on time.
Please note: we may send out like for like products from different manufacturers.
You can call us on 01455 616 444 or email [email protected]
Visit our trade counter: Unit 3 Claymill Road, Leicester, LE4 9JJ. We are open from Monday to Thursday 8am till 5pm and Friday 8am till 3pm.
Customers rate our excellent service at 4.8 out of 5, based on 812 reviews.
This can vary depending on the diameter you are looking at, please see the datasheet in the downloads which will provide you the information you require.
The wall thickness of the 350 AS BLACK is 0.7mm approx.
The maximum length we keep as stock is 10 meters, however we are able to supply this in various lengths but this would be made to order with a longer lead time. Please contact us with your requirements and we will be able to assist further.
The wall is a permanently antistatic premium esterpolyurethane (Pre-PUR®) and a spring steel wire firmly embedded in wall.
The temperature range of the 350 AS BLACK is -40°C to 90°C with a short time of 125°C.
The 350 AS BLACK is highly abrasion-resistant, and has a good resistance to oil, gasoline and chemicals.
The 350 AS BLACK has a permanently antistatic wall: according to ISO 8031 electrical and surface resistance <10⁹ Ω (according to TRGS 727 <2,5*10⁸ Ω*m and NFPA 652 10⁸-10⁹ Ω)
The applications for the 350 AS BLACK are as follows:
• flexible hose/ ducting for abrasive powder, bulk material, granulate and for gases
• air supply: UV dryer, IR dryer
• extraction unit, dedusting system, filter system, oil mist extraction
• explosion hazard area
• textile industry, fiber extraction: spinning machine, knitting machine, weaving loom machine
• clean room ventilation, semiconductor production machine
• heating hose: exterior hose as protection hose
• surface preparation: shot blasting/ sand blasting recovery e.g. at blasting chamber, ship yard, stripping machine, flooring preparation machine, grinding machine
Firstly, to connect flexible ducting to spiral you would require a male connection piece. You would then use a jubilee clip to secure the flexible ducting to the male connector.
To connect this ducting to express duct you would need a flex adapter. You would then use a jubilee clip to secure the flexible ducting to the express duct flex adapter.
