Helios GigaBox Centrifugal Box Fan 250mm Diameter 4 Pole Single Phase - 05509
The multifunctional Helios GigaBox is suitable for conveying medium to high volume flows against high resistances in ventilation systems. The compact frame design and installation-friendly accessories allow variable adaptation to structural conditions by simply moving the casing panels. Also available with EC drive technology for maximum efficiency.
Cubic ventilation box with intake and extract spigots, with flexible connectors to reduce vibration transmission and variable applicable side panels to suit to structural conditions. Simple positioning by standard crane hooks. Self-supporting enclosure frame construction made of aluminium hollow sections. Double-walled, 20 mm thick side panels made of galvanised sheet steel, sound and heat insulated by lining with non-combustible mineral wool. The enclosure panels can be replaced as required with accessories such as weather louvres and condensate trays. Additional accessories, wall bracket and weather protection roof can be mounted inside and outside as required. High-performance centrifugal impeller made of steel with backward curved blades on galvanised steel disc , directly driven. Vibration-free running due to dynamic balancing together with the motor in accordance with quality class 6.3 to DIN ISO 1940 T.1. Driven by single-phase AC external rotor motor, enclosed, maintenance-free design, speed controllable by voltage reduction, built-in thermal contacts wired in series with the winding, self-resetting, sealed, low-noise ball bearings with long-term lubrication. Mains connection at the terminal box integrated in the unit (IP54).
• Compact frame design and easy-to-install accessories for optimal adaptation to structural conditions.
• Any installation position due to five possible outlet directions.
• Optionally available with EC drive technology for even more energy-saving use.
• Simple installation with standard crane hooks.
• Extremely quiet operation.
Product Facts:
• Volume flows up to 0.147m3/s at 150 Pa approx. (529m3/hr)
• IEC-standard motor or maintenance-free external rotor motor protected to IP 54 or 44.
• Fully speed controllable
• Surrounding temperature from – 40° C to + 40° C.
• Terminal box protection to IP 54.
• The air flow direction of centrifugal fans is not reversible, but can be set by positioning the fan to the required air flow direction.
• RPM 1340 min-1
• Number of poles 4
• Voltage 230V, 1ph, 50Hz
• Rated current (FLC) uncontrolled 0.44 A
• Nominal power 95 W
• Weight 18,00 kg
• Wiring diagram no. 923
• Case breakout 26 dB(A) in 4 m
