Product SKU: 33001503030
£218.86 £262.63 inc VAT
In stock and ready for dispatch
Oil Mist Anti Static PROTAPE PUR Flexible Ducting 150mm Diameter 10 Meter Length (330-0150-3030)
Applications:
• extraction unit, dedusting system, filter system, oil mist extraction
• flexible hose/ ducting for gases and for abrasive dust, powder, fibres
• extraction arm
• explosion hazard area
• textile industry, fiber extraction: spinning machine, knitting machine, weaving loom machine
• animal stall, animal shed: barn ventilation
• clean room ventilation, semiconductor production machine
• surface preparation: shot blasting/ sand blasting recovery e.g. at blasting chamber, ship yard, stripping machine, flooring preparation machine, grinding machine
• heating hose: exterior hose as protection hose
Properties:
• lightweight and reinforced
• highly flexible + compressible 3:1
• abrasion-resistant
• good resistance to oil, gasoline and chemicals
• very good low temperature flexibility
• Permanently antistatic wall: according to ISO 8031 electrical and surface resistance <10⁹ Ω (according to NFPA 652 10⁸-10⁹ Ω)
• in accordance with ATEX 2014/34/EU (1999/92/EC) and German TRGS 727: aspiration of combustible dust (zone 22 inside), for conveying of non-flammable liquids, for use in zone 1 and 2 (gases)
• conforms to RoHS guideline
• REACH according to --> Technology / Technical Information / REACH
Temperature Range:
• -40°C to 90°C
• short time to 125°C
Design:
• PROTAPE® tape hose
• spring steel wire integrated in wall
• wall: permanently antistatic premium ester-polyurethane (Pre-PUR®)
• wall thickness 0,6 mm approx.
Please call if you require any assistance or help choosing the correct products. Our aim is to ensure that your purchase goes smoothly and is delivered on time.
Please note: we may send out like for like products from different manufacturers.
You can call us on 01455 616 444 or email [email protected]
Visit our trade counter: Unit 3 Claymill Road, Leicester, LE4 9JJ. We are open from Monday to Thursday 8am till 5pm and Friday 8am till 3pm.
Customers rate our excellent service at 4.8 out of 5, based on 824 reviews.
The 330 OIL is predominantly used within oil mist extraction systems. However, the other applications for the 350 OIL are as follows:
• extraction unit, dedusting system, filter system, oil mist extraction
• flexible hose/ ducting for gases and for abrasive dust, powder, fibres
• extraction arm
• explosion hazard area
• textile industry, fiber extraction: spinning machine, knitting machine, weaving loom machine
• animal stall, animal shed: barn ventilation
• clean room ventilation, semiconductor production machine
• surface preparation: shot blasting/ sand blasting recovery e.g. at blasting chamber, ship yard, stripping machine, flooring preparation machine, grinding machine
• heating hose: exterior hose as protection hose
This can vary depending on the diameter you are looking at, please see the datasheet in the downloads which will provide you the information you require.
The wall thickness of the 330 OIL is 0.6mm approx.
The maximum length we keep as stock is 10 meters, however we are able to supply this in various lengths but this would be made to order with a longer lead time. Please contact us with your requirements and we will be able to assist further.
The wall is a permanently antistatic premium ester-polyurethane (Pre-PUR®) with a spring steel wire integrated in wall.
The temperature range of the 330 OIL is -40°C to 90°C with a short time of 125°C.
Unfortunately the 330 OIL is not flame-retardant.
The 330 OIL is abrasion-resistant and has a good resistance to oil, gasoline and chemicals.
The 330 OIL has a permanently antistatic wall: according to ISO 8031 electrical and surface resistance <10⁹ Ω (according to NFPA 652 10⁸-10⁹ Ω).
Firstly, to connect flexible ducting to spiral you would require a male connection piece. You would then use a jubilee clip to secure the flexible ducting to the male connector.
To connect this ducting to express duct you would need a flex adapter. You would then use a jubilee clip to secure the flexible ducting to the express duct flex adapter.
